Ceramic Sintering Rotating Rotary Furnace 1100 C Purity Quartz Nitrogen Air Atmosphere

The RTF3042-0610 rotary furnace is suitable for the sintering of electronic products at and below 1100°C, and is also applicable to heat treatment in controllable atmospheres in sectors such as electronics, chemical engineering, machinery, and scientific research.

This product employs advanced infrared technology and advanced furnace lining materials, enhancing the thermal efficiency of the equipment; it utilizes advanced temperature control technology to ensure the precision of temperature control; by using mature furnace body design technology, it guarantees the uniformity of furnace temperature; with the use of a large-diameter quartz furnace tube, it ensures the cleanliness of products, thereby guaranteeing the sintering quality of products.

• Equipment Model: RTF3042-0610 Rotary Furnace
• Temperature Range: Maximum temperature 1000°C
• Operating Temperature: Room temperature (RT) to 900°C
• Furnace Tube Dimensions: Φ300mm × 4230mm
• Number of Temperature Control Zones: 6, each zone is 420mm long, with K-type thermocouples
• Temperature Control Accuracy: ±1°C
• Temperature Control Mode: Uses a Yokogawa (Japan) temperature controller, with adjustable heating rate
• Heating Elements: Far-infrared FEC heating panels
• Atmosphere Inside the Furnace: Air
• Cooling Method: Air cooling
• Heating Time for an Empty Furnace: ≥180 minutes (from room temperature to 900°C)
• Maximum Heating Power: 48 kW
• Power Consumption for Holding an Empty Furnace: ≤12 kW
• Power Requirements: 380V ± 10%, 50Hz, 3-phase 5-wire
• Overall Dimensions: 6200 × 1215 × 2475mm (L × W × H)

1. Environmental Conditions: temperature: 0~40ºC, humidity ≤ 80%RH, no corrosive gas, no strong airflow disturbance
2. Gas Source Conditions: High-purity nitrogen, with a purity of 99.999%, pressure range of 0.2 - 0.4 MPa
3. Ventilation System: non-contact access to the user pumping system, pumping capacity is greater than 30 m³/h
4. Ground Requirements: horizontal, no obvious vibration, load-bearing > 500 Kg/m²
5. Power Condition(TBD): capacity > 64kVA, 3-phases 5-lines, voltage 220/380V, frequency 50Hz. Fire line: yellow, green, red, Zero line: blue, Ground line: yellow-green
6. Installation Site: 8000mm×2000mm×3000mm(L×W×H), with an installation area greater than 16m²
