Industrial Clean Quartz Rotary Furnace 1050C For Ceramic Sintering

Name: Industrial Clean Quartz Rotary Furnace 1050C For Ceramic Sintering
Brand: Chitherm
Price: 1 USD

China Industrial Clean Quartz Rotary Furnace 1050C For Ceramic Sintering wholesale

Place of Origin : China

Brand Name : Chitherm

MOQ : 1

Price : Negotiable

Packaging Details : Customized

Delivery Time : Customized

Payment Terms : Customized

Supply Ability : 50 Sets/Year

Model Number : RTF3042-0610

Range of Applications : Industrial

Type : Electric Holding Furnace

Usage : Ceramic Sintering

Fuel : Electric

Atmosphere : Nitrogen/Air

Effective Chamber Dimensions : Inner Diameter Φ300*4230

Transport Package : Wooden Packaging

Specification : 1215*2500*6200mm(W*H*L)

Trademark : Chitherm

Origin : China

HS Code : 8514101000

Customization : Available

Certification : ISO

Place Style : Vertical

Contact Now

Industrial Clean Quartz Rotary Tube Furnace 1050°C For Ceramic Sintering

Product Specifications

Attribute	Value
Range of Applications	Industrial
Type	Electric Holding Furnace
Usage	Ceramic Sintering
Fuel	Electric
Atmosphere	Nitrogen/Air
Effective Chamber Dimensions	Inner Diameter Φ300*4230
Transport Package	Wooden Packaging
Specification	121525006200mm(WHL)
Trademark	Chitherm
Origin	China
HS Code	8514101000
Supply Ability	50 Sets/Year
Customization	Available
Certification	ISO
Place Style	Vertical

Product Description

The Chitherm 1050°C RTF3042-0611 Clean Rotary Furnace offers customizable solutions for diverse industrial applications with precision temperature control and uniform heating.

Performance Parameters

Maximum Temperature: 1000°C
Operating Temperature: RT~900°C
Actual Furnace Tube Size: Φ300mm×4230mm
Heating Zone Length: 2770mm
Temperature Zones: 6 zones with K-type thermocouple
Temperature Control Accuracy: ±1°C
Control Method: Shimaden temperature controller (Japan) with adjustable heating rate
Heating Method: Far-infrared FEC heater
Furnace Atmosphere: Air
Cooling Method: Air cooling
Control System: Imported single-loop intelligent temperature controller with PID auto-tuning
Alarm Protection: Audible/visual alarms for thermocouple breakage and overtemperature
Surface Temperature Rise: ≤35°C

Furnace Layout

Transition Cooling Zone: 1 zone (840mm length)
Heating Zone: 6 zones (2770mm length), temperature range RT~900°C

Atmosphere System

Working Atmosphere: Clean, dry, oil-free compressed air (0.4~0.8Mpa, 3~7m³/h flow)
Controlled Atmosphere: 1 path with glass rotor flow meter control

Installation Requirements

Indoor installation with ambient temperature range -15°C to 45°C
Environment must be free of flammable, corrosive gases and steam
Minimum floor area: 24m² with 8m length × 3m width × 3m height workspace
Sturdy, level foundation required (total furnace weight: ~2100kg)
Power supply: Three-phase five-wire AC 380±10%V, 50±2%Hz dedicated line
Prohibited equipment on same circuit: welding machines, electric furnaces, metal cutting machines
Reliable grounding mandatory

Industrial Clean Quartz Rotary Furnace 1050C For Ceramic Sintering

Delivery Contents

Item	Note	Quantity
Basic Components	Furnace	1 SET
Inspection Certificate	Certificate of major outsourced components	1 SET
Technical Documents	Instructions, technical documents of major outsourced parts	1 SET
Key Components	Heating Element	1 SET
Touch Screen		1 SET
Temperature Controller		1 SET
Quartz tube	SiO2	1 PC
Reducer motor		1 SET
Spare Parts	SSR	1 PC
